Samsung IW012J The Wall Professional Panel- Indoor Direct View LED Display - TAA Compliant - Pixel Pitch 1.26mm


The Wall Professional -IW012J

IW012J MicroLED Video Wall Display Panel (TAA-Compliant)

Experience a new level of greatness, complete with included S-Box signage player, magnetic jig, mount frame kit, installation supervision service and a 3-year onsite warranty.

At a glance
Samsung's The Wall Professional Bundle packages the modular, bezel-less MicroLED display with the accessories and service you need to easily install, manage and maintain your signage and content. Samsung's The Wall Professional features MicroLED technology that delivers a revolutionary viewing experience with pure black, true color and epic clarity. Ideal for high-end retail stores, hotel lobbies, VIP stadium suites, conference rooms and more, The Wall Professional redefines what it means to deliver a one-of-a-kind visual experience.
  • S-Box Signage Player lets you deliver stunning content thanks to image quality enhancement, versatile connectivity and easy management
  • Complete with a mount frame kit and side deco for 4x4 configurations and a magnetic jig to easily replace modules
  • 3-year onsite warranty to secure your peace of mind
  • Installation supervision service to assist you in getting your cabinets installed and ready to go
low reflection black technology

Perfect Blacks

The fusion of an exceptionally black base with a specialized ultra-low reflection technology delivers levels of the purest blacks. Unmatched black is how The Wall Professional is able to produce unparalleled contrast and spectacular detail.

LED color

True Colors, True Beauty

With two times the color purity of conventional LEDs and a wider color gamut, The Wall Professional produces extremely accurate, true-to-life colors, for an incredibly immersive viewing experience.

HDR10+ display

Greater Refinement

Experience cutting-edge innovation with MicroLED technology. The Wall Professional’s industry-leading picture quality engine—advanced HDR picture refinement, HDR10+ and more—possesses an intuitive capability to render optimum peak brightness and extremely accurate grayscale expression for true-to-life imagery.

Great Modularity

The Wall Professional is sleek and gorgeous and flexible. Its modular design means you’re no longer restricted to a simple rectangle. Customize The Wall Professional to a variety of sizes and designs according to spatial needs and aesthetic desires.

Sleek Design

A slim depth with a seamless, flush surface allows The Wall Professional to be an aesthetic complement for any environment, whether it be a corporate lobby, trendy museum or luxury residence.

Exceptional Durability

The Wall Professional delivers protection against everyday impact through special shock-resistant technology. Combined with exceptional energy efficiency and long MicroLED life, The Wall Professional provides long-lasting, reliable use.

S-Box Signage Player (not included)
Samsung's S-Box Signage Player features powerful processing and fast performance. With image quality enhancement, versatile connectivity options and MagicINFO digital signage software for easy management, this media player delivers stunning content.

Physical Parameter

    • Pixel Pitch1.26mm
    • Pixel Configuration1 red, 1 green, 1 blue
    • Configuration (LxH, per cabinet)640x360 pixels
    • Diode TypeFlip-chip RGB LED
    • Dimensions (W x H x D, Cabinet)806.4x453.6x72.2 mm
  • Dimensions (inch, inchxD, per cabinet)36.4 x 2.8 inch
  • No. of Modules (WxH, per cabinet)4 x 3
  • Weight (per cabinet/per ㎡)12.2Kg / 33.4Kg

Optical Parameter

    • ProcessorSnow processor
    • Brightness (Peak/Max)(1)1,600 nit / 800 nit
    • Contrast Ratio(2)24,000 : 1
  • HDR CompatibilityLED HDR / HDR10+ support / Multi-link HDR
  • Viewing angle - Horizontal160°
  • Viewing angle - Vertical140°
  • Bit Depth16 bit (Internal processing 20bit)
  • CalibrationD Gamma / Pixel to Pixel / Module to Module / Quality Mode
  • Color Temperature - Default6,500K+-500K (Floating bin)
  • Color temperature - Adjustable2,800K~10,000K (using S-BOX)

Electrical Parameter

    • Video Rate50/60 Hz
    • Input Power Range100~240 VAC, 50/60 Hz
    • Power consumption - Max410 (W/㎡) / 150 (W/Cabinet)
    • Power consumption - Typical328 (W/㎡) / 120 (W/Cabinet)
    • Heat Generation - Max512 (BTU/Cabinet) / 1,399 (BTU/m²)
    • Heat Generation - Typ410 (BTU/Cabinet) / 1,120 (BTU/m²)
  • Refresh rate3,840 Hz

Operation Conditions

  • Power RedundancyYes
  • Working Temperature / Humidity0°C~+40°C/10~80%RH
  • Storage Temperature / Humidity-20°C ~ +45°C / 5% ~ 95%RH
  • IP RatingIP20
  • LED Lifetime100,000 hours


  • ConnectivityHDBT


  • MagicINFOYes
  • SensorTemperature
  • Operating SystemTizen
  • OtherEco Image Enhancer


  • CertificationEMC Class B, Safety 60950-1


  • ServiceFront


  • Box Dimension (WxDxH)940 x 587 x 199
  • Box Volume (m3)0.11
  • Package Weight (kg, per cabinet)16.6kg


  • AccessoriesDécor Frame (Standard), Frame Kit
  • Remote Control-


  • Disclaimer(1)Peak Value according to IDMS (Information Display Measurement Standard)
  • Disclaimer(2)Measured under 10lux light. Contrast in darkroom exceeds 1000000:1
