AVer COMSCA540 4k 16x PTZ USB conference camera



Super sharp, accurate color, up to 4K

Finally the term "Like looking through glass" can be used. The CAM540 uses high quality sensors and multi-lens glass to produce the sharpest and most accurate color ever.
10 camera presets

The CAM540 allows you to customize your meetings by storing up to 10 PTZ presets by RS232 VISCA or UVC. 10 camera presets can be easily accessed with one touch of the remote, saving you time and providing flexibility to swiftly move to predetermined locations in your conference room.
Easy plug-and-play, any app!

The CAM540 is an affordable, professional-grade USB PTZ camera optimized to deliver an exceptional video communication experience. Compatible with all of your favorite apps, Cloud Services and audio systems. The CAM540 connects to virtually any desktop or laptop via a single USB cable.
Tricky light condition, no problem

No matter if you are in low, bright, fluorescent or natural light -- AVer’s CAM540 optimizes light balance to create natural-looking skin tones and enhance faces providing you with accurate color to its fullest.
16X zoom with PTZ

With one of the fastest and smoothest true 16X zoom wide angle cameras available on the market today, the CAM540's multi-element, multi-coating auto-focus optics and 16X zoom delivers rapid and smooth pan, tilt and zoom-in performance to capture the smallest details with absolute clarity at every focal length.


Perfectly frame everyone in the room, no matter their distance from the lens with a single click.
RS232 VISCA integration capabilities

With advanced integration capabilities built into the CAM540 camera, including an RS232 cable and VISCA support, the system can easily be integrated into a controlled environment allowing users to operate and manage the CAM540 through an AV control panel.
Motorized Pan and Tilt Movement
Pan: ±160°
Tilt: +90° (up) -30° (down)
10 camera presets (through remote control)
Quiet and smooth pan and Tilt movement

Ultra-crystal clear image supports up to 4K
Frame rate: 4K@30fps, 1080, 720p , 640x480, 320x240 @ 60,30,15 fps*
AutoFraming based on facial recognition for an optimal hands free experience
16X HD Zoom (3.3xOptical + Digital)**
86° Field of View
Immediate auto focus: minimum working distance 1 meter
Backlight compensation and 2D noise reduction technology for optimizing light balance in tricky conditions
12V power adaptor
Mini DIN6 for RS232 connection
USB Type C connector
Video Format

2.0, 3.1 Gen1
UVC (USB Video Class) 1.1

IR remote control
VISCA/pelco P/pelco D via RS232
UVC/ plug-and play

Security and Mount

Camera mount included for wall or ceiling
Kensington slot
Standard tripod thread

System Requirements*
Windows 7/8/8.1/10
Mac OS X 10.7 or higher
Google Chromebook version 29.0.1547.70, platform 4319.79.0

Hardware Specs*
2.4GHz Intel@ Core 2 Duo processor
2GB RAM or more
USB 3.1 Gen1 port

PTZapp Application
Compatible with SkypeTM Plugin for answering and hanging up via remote control
Upgrade firmware automatically or manually
Control camera
Set parameters and adjust camera image
Diagnose operating status
View live video
Free download on Windows® and Mac® computers

Power Supply
AC 100V ~240V, 50/60Hz, 3 meters
Consumption: 12V, 2A

Environmental Data

Operation temperature: 0 ~40°C, Operation humidity: 20% ~80%
Storage temperature: -20 ~60°C, Storage humidity: 20% ~80%

Package dimensions: 227*189*261mm
Package weight: 2.54 kg
Camera: 97.8 x 130.7 x 171.1 mm/1.5kg
Remote Control: 200 x 50 x 21 mm/0.09kg

Package Contents
Camera, Remote control, Power adapter
USB3.1 type-C to type-A (6ft), USB3.1 type-A to type-C adapter
Quick-start guide
Metal mount, tripod screw, Battery

Optional Accessories
Mini DIN6 to RS232 adapter, 16ft (5m) USB 2.0 cable

Camera : 3+2 year, Accessories: 1 year

Compatible Applications
ZOOM, Adobe Connect, BlueJeans, CyberLink U Meeting®, Cisco WebEx®, Google Hangout, GoToMeeting™, Intel® Unite™, Microsoft® Lync™, Skype™, Skype for Business, V-Cube, vMix, WebRTC, Wirecast, XSplit
