QNAP VS-8324-US 8 Bay NVR, 24CH (Max Channels 48), VMS Built-In, IP Surveillance, HDMI Output For Local Display


The QVR Pro Appliance is a SMB-grade; tower-based network surveillance server that supports high quality real-time video/audio monitoring, megapixel recording, and playback from multiple IP cameras to safeguard your precious property and assets.

CPU Intel® Core™ i5-8400T
Frequency 6-core/6-thread 1.7 GHz base/3.3 GHz turbo
Architecture x86 64-bit
Encryption engine AES-NI, AES-256
Graphics Intel® UHD Graphics 630
Pre-installed memory 16 GB RAM: 2 x 8 GB SODIMM DDR4 SODIMM
Memory slots 2 x SODIMM DDR4
Maximum memory 32 GB RAM: 2 x 16 GB
Flash memory 5G USB DOM
Drive bays 8 x 3.5-inch SATA 6 Gbps, 8 x 2.5-inch SATA 6 Gbps
Drive compatibility 3.5-inch bays:
3.5-inch SATA hard disk drives
2.5-inch bays:
2.5-inch SATA hard disk drives
2.5-inch SATA solid-state drives
Drive tray type Key lock
M.2 SSD form factor 2280
Hot-swapping The device supports hot-swapping drives
Gigabit Ethernet ports 2 x GbE RJ45
PCIe slots 1 x PCIe 3.0 x16, 1 x PCIe 3.0 x 4
USB ports 2 x USB 3.1 Gen2 10Gbps 5V/3A Type-C
2 x USB 3.1 Gen2 10Gbps 5V/1A Type-A
HDMI ports 1 x HDMI 2.0 ( up to 3840 x 2160 at 60Hz)
Audio ports 1 x 3.5 mm dynamic microphone jacks, 1 x 3.5mm line out jack (for ampfliers or speakers)
Display panel Monochrome backlit LCD display
Buttons Power
USB One Touch Copy
Form factor Tower
Dimensions (H x W x D) 188.2 × 329.3 × 279.6 mm
7.41*12.96*11 inch
Net weight 7.06 kg (15.56 lbs)
Power supply unit 250W, 100-240V AC, 50/60 Hz
System battery CR2032 lithium battery (3V, 225 mAh)
Sound level 24.2 db(A)
Fans System: 2 x 120 mm, 12V DC smart fan
CPU: 2 x 60mm, 12V DC smart fan
Operating temperature 0˚C to 40˚C (32˚F to 104˚F)
Relative humidity Non-condensing relative humidity: 5% to 95%
Wet-bulb temperature: 27˚C (80.6˚F)
Security slot Kensington security slot
