Samsung IW008R The Wall Professional Panel- Indoor Direct View LED Display - TAA Compliant - Pixel Pitch 0.84mm


The Wall Professional -IW008R

IW008R MicroLED Video Wall Display Panel (TAA-Compliant)


Experience Greatness

The Wall is a new generation of display technology delivering a truly exclusive experience. Unparalleled in its visuals and designed to refine, the bespoke build gives any space an awe-inspiring edge. Inspired by emotion. Powered by intelligence. A bold statement, but one that blends in perfectly.

See the Greatness

Black Seal icon black version

Black Seal Technology

The fusion of an exceptionally black base with specialized Black Seal Technology, delivers pure black levels for unparalleled contrast and immaculate detail. This technology also protects the screen from impact and dust, even at close proximity.

Black Seal Technology

Ultra Chroma Technology icon black version

Ultra Chroma Technology

The Wall’s Ultra Chroma Technology produces vibrant, yet natural colors for a true-to-life visual experience. A narrower wavelength of color results in higher color purity, approximately two times better* than conventional LEDs, for more precise and accurate color presentation.

*Figure is based on internal testing standards against Samsung's conventional LED Signage.

Quantum Processor Flex

The Wall’s AI upscaling technology, powered by the Quantum Processor Flex, creates visual innovation with no boundaries. The intuitive resolution-to-screen size adjustment capability, delivers a perfect view of reality in any size up to 8K for a truly immersive experience.

Quantum Processor Flex

Quantum Processor Flex

Total UX

Going beyond the traditional viewing platform, The Wall becomes a digital canvas to showcase various forms of media. You can watch your favorites and exhibit your personal style through two distinct modes with easy-to-use controllers.

    • circle entertainment modeEntertainment mode
  • circle ambient modeAmbient mode

Total UX 1

Ambient Mode

My W Edition/Background Theme

Preset and customizable wall templates with Samsung original wall backgrounds

My W Edition/Background Theme


Refined, moving decorative pieces

My W Edition/Background Theme

Art/Media Art

Photographs, paintings and digital art

My W Edition/Background Theme

My Collection

Your own personal image collection

My W Edition/Background Theme

* Some features require a compatible tablet remote, provided by a 3rd party, to operate.
* The user interface shown may not operate in certain aspect ratios.

Infinity design

The Wall seamlessly blends into its surroundings with a slim, bezel-less design. Furthermore, The Wall’s frame features a refined, subtle-but-sleek finish that can be customized* to reflect the design elements of any room.

Infinity design 2

Infinity design 1

Infinity design 2

Infinity design 1

* Customization is provided by a third party

Total ecosystem

Designed for a seamless full-scale experience, The Wall synchronizes harmoniously with various elements of a luxury entertainment system, including audio and home automation, while also providing diverse content options.

The Wall feature image 01

Physical Parameter

    • Pixel Pitch0.84mm
    • Pixel Configuration1 red, 1 green, 1 blue
    • Configuration (LxH, per cabinet)960x540 pixels
    • Diode TypeFlip-chip RGB LED
    • Dimensions (W x H x D, Cabinet)806.4x453.6x29.9 mm
  • Dimensions (inch, inchxD, per cabinet)36.4x1.2 inch
  • No. of Modules (WxH, per cabinet)4 x 3
  • Weight (per cabinet/per ㎡)11.5Kg / 31.4Kg

Optical Parameter

    • ProcessorQuantum processor Flex
    • Brightness (Peak/Max)(1)2,000 nit / 250 nit
    • Contrast Ratio(2)30,000 : 1
  • HDR CompatibilityLED HDR, HDR10+ Support
  • Viewing angle - Horizontal155°
  • Viewing angle - Vertical135°
  • Bit Depth16 bit (Internal processing 20bit)
  • CalibrationD Gamma / Pixel to Pixel / Module to Module / Quality Mode
  • Color Temperature - Default8,500K+-1,000K(floating Bin)
  • Color temperature - Adjustable6,500K~10,000K (use M/BOX)

Electrical Parameter

    • Video Rate100/120 Hz
    • Input Power Range100~240 VAC, 50/60 Hz
    • Power consumption - Max465 (W/㎡) / 170 (W/Cabinet)
    • Power consumption - Typical410(W/㎡) / 150 (W/Cabinet)
    • Heat Generation - Max580 (BTU/Cabinet) / 1,586 (BTU/m²)
    • Heat Generation - Typ512 (BTU/Cabinet) / 1,400 (BTU/m²)
  • Refresh rate3,840 Hz

Operation Conditions

  • Working Temperature / Humidity0°C~+40°C / 10%~80%RH
  • Storage Temperature / Humidity-20°C~+45°C / 5%~95%RH
  • IP RatingIP20
  • LED Lifetime100,000 hours


  • ConnectivityOptical ※ HDBT is used for connecting only BT/Wifi module


  • SensorAmbient Light / Temperature
  • Other-
  • Smart TV typeSmart
  • Smart FunctionEntertainment Mode, Ambient Mode, Apps (Netflix, YouTube, Apple TV, etc.), Bixby (Voice), SmartThings (IoT)
  • Bixby LanguageUS English, Korean, UK English, French, German, Italian, Spanish (features vary by language)


  • CertificationEMC Class B, Safety 60950-1


  • ServiceFront


  • Box Dimension (WxDxH)940 x 587 x 162
  • Box Volume (m3)0.089
  • Package Weight (kg, per cabinet)16.1 kg

Smart Function

  • Smart FunctionEntertainment Mode, Ambient Mode, Apps (Netflix, YouTube, Apple TV, etc.), Bixby (Voice), SmartThings (IoT)


  • AccessoriesDécor Frame (Standard), Frame Kit ※ Provide Décor Frame Customizable Guide
  • Remote ControlTablet App, Smart Control


  • Disclaimer(1)Peak value according to IDMS (Information Display Measurement Standard)
  • Disclaimer(2)Measured under 10lux light. Contrast in darkroom exceeds 1000000:1
