| Product SKU |
IPC2128SR5-ADF40KM-G |
| Brand |
Uniview |
| Condition |
New |
| NDAA Compliance |
Yes |
| Features |
Audio, Auto Gain Control, Automatic White Balance, Back Light Compensation, Day/Night, Digital Noise Reduction, Motion Detection Tracking, On Screen Display Menu, ONVIF, Privacy Masking, Weather Resistant, Wide Dynamic Range, 4K Resolution |
| IR Distance |
50m/164ft |
| S/N Ratio |
>56dB |
| Protocols |
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL/TLS, QoS, 802.1x, SNMP |
| Privacy Zone |
Up to 4 areas |
| Power Consumption |
Max 6.5W |
| OSD Menu |
Up to 4 OSDs |
| Operating Temperature |
-30°C ~ +60°C (-22°F ~ 140°F) |
| Operating Humidity |
≤95% RH(non-condensing) |
| Minimum Scene Illumination |
Colour: 0.005Lux ( F1.6, AGC ON)0Lux with IR on |
| Lens Size |
4mm |
| Camera Signal |
Network IP |
| Lens Type |
Fixed |
| Rotation Angle |
Rotate: 0° to 360° |
| Angle of View |
(H): 91°, (V): 47.9°, (O): 95.9° |
| Digital Noise Reduction |
2D/3D DNR |
| Weatherproof |
IP67 |
| IR Wavelength |
850nm |
| Motion Detection Tracking |
Up to 4 areas |
| Back Light Compensation |
Supported |
| Automatic White Balance |
Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
| Infrared Distance |
101 Feet + |
| Resolution |
8 Megapixel (4k) |
| Voltage |
12vDC, PoE |
| Compression Method |
Ultra 265, H.264, M-JPEG, H.265 |
| Connection Type |
Wired |
| Image Device |
1/2.7", 8.0 megapixel, progressive scan, CMOS |
| Electronic Shutter |
Auto/Manual, 1~1/100000 s |
| Dimensions (W x H) |
190×73×71mm (7.5”×2.9”×2.8”) |
| Durability |
Weather Resistant |
| Mount Type |
Ceiling, Wall |
| Audio |
Yes |
| Motion Detection Tracking |
Yes |
| On Screen Display Menu |
Yes |
| Privacy Masking |
Yes |
| Wide Dynamic Range |
Yes |
| ONVIF |
Yes |
| Auto Gain Control |
Yes |
| Day/Night |
Yes |
| Digital Noise Reduction |
Yes |
| Automatic White Balance |
Yes |
| Back Light Compensation |
Yes |
