| Product SKU |
IPC6634S-X33-VF |
| Brand |
Uniview |
| Condition |
New |
| NDAA Compliance |
Yes |
| Features |
Audio, Auto Gain Control, Automatic White Balance, Back Light Compensation, Day/Night, Digital Noise Reduction, Motion Detection Tracking, On Screen Display Menu, ONVIF, Privacy Masking, Vandal Resistant, Weather Resistant, Wide Dynamic Range |
| S/N Ratio |
>56dB |
| Protocols |
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP, SSL/TLS |
| Privacy Zone |
24 areas, up to 4 areas per scene |
| Power Consumption |
Max 16W |
| OSD Menu |
Up to 8 OSDs |
| Operating Temperature |
-40°C ~ 70°C (-40°F ~ 158°F) |
| Operating Humidity |
≤95% RH (non-condensing) |
| Minimum Scene Illumination |
Colour: 0.003Lux (F1.5, AGC ON)BW: 0.001Lux (F1.5, AGC ON) |
| Lens Size |
33X |
| Camera Signal |
Network IP |
| Lens Type |
Motorized Zoom |
| Angle of View |
(H): 53.0° ~ 2.3°, (V): 40.5° ~ 1.7°, (O): 65.2° ~ 2.7° |
| Digital Noise Reduction |
2D/3D DNR |
| Weatherproof |
IP67 |
| Video Output |
1 BNC |
| Back Light Compensation |
Support |
| Automatic White Balance |
Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
| Infrared Distance |
Non Infrared |
| Resolution |
4 Megapixel |
| Voltage |
24vDC, 24vAC, PoE |
| Compression Method |
Ultra 265, H.264, M-JPEG, H.265 |
| Connection Type |
Wired |
| Image Device |
1/2.8", 4.0 megapixel, progressive scan, CMOS |
| Electronic Shutter |
Auto/Manual, 1 ~ 1/100000s |
| Dimensions (W x H) |
Φ218 x 297mm (Φ8.6” x 11.7”) |
| Durability |
Vandal Resistant, Weather Resistant |
| Mount Type |
Pendant |
| Audio |
Yes |
| Motion Detection Tracking |
Yes |
| On Screen Display Menu |
Yes |
| Privacy Masking |
Yes |
| Wide Dynamic Range |
Yes |
| ONVIF |
Yes |
| Auto Gain Control |
Yes |
| Day/Night |
Yes |
| Digital Noise Reduction |
Yes |
| Automatic White Balance |
Yes |
| Back Light Compensation |
Yes |
