64CH 4K NVR Gigabit, NO HDD
- Free shipping
- 3-year Silarius warranty
- US-based support team
Buying in volume or for several sites? Get project pricing.
Add Silarius Live Monitoring. Trained operators watch every camera on this recorder at night, on weekends or 24/7, warn intruders off and call the police. Works with any camera system. From $69.99 per camera a month, no contract. Add monitoring
Complete your setup
Everything this needs to work on day one. Add with one tap.
SIL-XT5MP28AU5MP IR Turret Network CameraPopular 5MP turret, indoor or outdoor$199.99
SIL-XB5MP28AU5MP IR Fixed Bullet Network CameraPopular 5MP bullet for outdoor coverage$199.99
SIL-B16M3POE1G30016 Ports 10/100/1000Mbps Gigabit Layer3 Managed PoE+ switch with 4 Ports 10G SFP+ Uplink,1USB, 1 Console, 6KV surge protection,300W,rack mount installationPoE power for more cameras$220.00
HDMI Cable (15 Feet) Ultra HDMI 2.0V Support 4K 2160P, 1080P, 3D, Audio Return and Ethernet - 1 Pack 15'Connect a monitor$8.99
Specifications
System
| Main Processor | ARM Cortex A17 Quad-core Processor |
|---|---|
| Operating System | Embedded LINUX |
Video
| Input | 64CH(4000×3000, 3840×2160, 2592x1944, 2048x1536, 1920×1080, 1280×960, 1280×720, etc) |
|---|---|
| Output | 1 VGA, 2 HD |
Audio
| Input | 1 Port RCA |
|---|---|
| Output | 1 Port RCA(Linear, 1kΩ) |
| Audio Bit Rate | 64kbps |
| Audio Compression | AAC,G711u, G711a, ADPCM_DVI4 |
| Intercom | support (two-way) |
Alarm
| Sensor Input | 16 |
|---|---|
| Output | 4 |
| Motion Detection | 64 Channel, MD Zones: 396 (22 × 18) |
| Trigger Events | Recording, Email, FTP, Snapshot, Buzzer and Screen Tips, alarm output |
Display
| HD Output1 | 4K (3840 × 2160)/30Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz |
|---|---|
| HD Output2 | 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz |
| VGA Resolution | 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz |
| Display Split | 64CHxD1/36CHxD1/25CHxD1/16CHxD1/9CHxD1/4CHxD1/1CHx1080P/1CHx3MP/1CHx4MP/1CHx5MP/1CHx4k/1CHx12MP |
| Digital Zoom | YES |
| OSD | Camera Title, Time, Recording, Motion Detection, Event Alarm |
Recording
| Video Compression | H265/H264/H265+/H264+ |
|---|---|
| Record Rate | PAL:12MP@29×25fp,4k@35×25fp,5MP@58×25fp,4MP@64x25fp,3MP@64×25fp,1080P@64×25fp, 960P@64×25fp,720P@64×25fp, |
| NTSC | 12MP@29×30fp,4k@35×30fp,5MP@58×30fp,4MP@64×30fp,3MP@64×30fp,1080P@64×30fp, 960P@64×30fp, 720P@64×30fp, |
| Record Mode | Manual\Timer\Motion Detection\Smart Event |
Playback & Backup
| Local Sync Playback | 3CH 12MP@15fps, 4CH 4K@30fps, 6CH 5MP@30fps, 8CH 4MP@30fps, 10CH 3M@30fps, |
|---|---|
| Decode Capability | 4CH 4K(3840×2160)@30fps |
| Remote Sync Playback | YES |
| Search Mode | ALL, Channel, Manual, Time, Date, Motion Detection,Event Alarm,Tag search |
| Playback Functions | Play, Pause, Stop, Rewind, Fast play, Slow Play, Full Screen, Frame Play ,Frame Rewind, Digital Zoom,tag,clip |
| Backup Mode | USB Device/Network |
Network
| Interface | 2 RJ-45 10/100/1000Mbps self-adaptive Ethernet interfaces |
|---|---|
| Incoming Bandwidth | 300MB |
| Network Functions | TCP/IP, HTTP, UPnP, DNS, NTP, SMTP, DHCP, FTP, DDNS, RTSP, RTCP, p2p,PPPOE |
| Onvif Version | onvif S,onvif T |
| Web Browser | Edge,IE8-11, Google Chrome , Firefox ,Safari |
| Smart Phone | iPhone, iPad, Android, Android Pad |
| POE | / |
Storage
| Interface Type | 8 SATA Hard Disk Interface (3.5" SATA) |
|---|---|
| Capacity | Up to 48TB capacity |
| eSATA | 1 eSATA interface |
General
| Language | Traditional Chinese, Simplified Chinese, English, Polish, Czech, Russian, Thai, Hebrew, Arabic, Bulgarian, |
|---|---|
| USB Interface | 2 USB 2.0 Interfaces ,1 USB 3.0 Interface |
| RS485 | 2 Port |
| Power Supply | AC 115V to 230V,3A |
| Working Environment | -10~55℃/10~90% |
| Dimension(W×D×H) | 2U, 440mm×450mm×95mm |
| Weight | 9.8Kg（without HDD） |
Full description
System
Main Processor: ARM Cortex A17 Quad-core Processor
Operating System: Embedded LINUX
Video
Input: 64CH(4000×3000, 3840×2160, 2592x1944, 2048x1536, 1920×1080, 1280×960, 1280×720, etc)
Output: 1 VGA, 2 HD
Audio
Input: 1 Port RCA
Output: 1 Port RCA(Linear, 1kΩ)
Audio Bit Rate: 64kbps
Audio Compression: AAC,G711u, G711a, ADPCM_DVI4
Intercom : support (two-way)
Alarm
Sensor Input: 16
Output: 4
Motion Detection: 64 Channel, MD Zones: 396 (22 × 18)
Trigger Events: Recording, Email, FTP, Snapshot, Buzzer and Screen Tips, alarm output
Display
HD Output1: 4K (3840 × 2160)/30Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
HD Output2: 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
VGA Resolution: 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
Display Split: 64CHxD1/36CHxD1/25CHxD1/16CHxD1/9CHxD1/4CHxD1/1CHx1080P/1CHx3MP/1CHx4MP/1CHx5MP/1CHx4k/1CHx12MP
Digital Zoom: YES
OSD: Camera Title, Time, Recording, Motion Detection, Event Alarm
Recording
Video Compression: H265/H264/H265+/H264+
Resolution:
12MP(4000×3000),4k(3840×2160),5MP(2592×1944),4MP(2688×1520/2560×1440),
3MP(2048×1536),1080P(1920×1080),960P(1280x960),720P(1280×720),D1 (720×576/720×480)
Record Rate: PAL:12MP@29×25fp,4k@35×25fp,5MP@58×25fp,4MP@64x25fp,3MP@64×25fp,1080P@64×25fp, 960P@64×25fp,720P@64×25fp,
D1@64×25fp
NTSC:12MP@29×30fp,4k@35×30fp,5MP@58×30fp,4MP@64×30fp,3MP@64×30fp,1080P@64×30fp, 960P@64×30fp, 720P@64×30fp,
D1@64×30fp
Record Mode: Manual\Timer\Motion Detection\Smart Event
Playback & Backup
Local Sync Playback: 3CH 12MP@15fps, 4CH 4K@30fps, 6CH 5MP@30fps, 8CH 4MP@30fps, 10CH 3M@30fps,
16CH 1080P@30fps, 16CH 960P@30fps, 16CH 720P@30fps,16CH D1@30fps
Decode Capability: 4CH 4K(3840×2160)@30fps
Remote Sync Playback: YES
Search Mode: ALL, Channel, Manual, Time, Date, Motion Detection,Event Alarm,Tag search
Playback Functions: Play, Pause, Stop, Rewind, Fast play, Slow Play, Full Screen, Frame Play ,Frame Rewind, Digital Zoom,tag,clip
Backup Mode: USB Device/Network
Network
Interface: 2 RJ-45 10/100/1000Mbps self-adaptive Ethernet interfaces
Incoming Bandwidth: 300MB
Network Functions:TCP/IP, HTTP, UPnP, DNS, NTP, SMTP, DHCP, FTP, DDNS, RTSP, RTCP, p2p,PPPOE
Onvif Version: onvif S,onvif T
Web Browser: Edge,IE8-11, Google Chrome , Firefox ,Safari
CMS Software Support Windows 7/ Windows 8/Windows 10/MAC OS
Cloud Support(P2P) Yes
Smart Phone: iPhone, iPad, Android, Android Pad
POE: /
WIFI /
Storage
Interface Type: 8 SATA Hard Disk Interface (3.5" SATA)
Capacity: Up to 48TB capacity
eSATA: 1 eSATA interface
General
Language: Traditional Chinese, Simplified Chinese, English, Polish, Czech, Russian, Thai, Hebrew, Arabic, Bulgarian,
German, French, Portuguese, Turkic, Spanish, Italian, Hungarian, Romanian, Korean, Dutch, Greek, Vietnamese,Janpanese
USB Interface: 2 USB 2.0 Interfaces ,1 USB 3.0 Interface
RS485: 2 Port
Power Supply: AC 115V to 230V,3A
Working Environment: -10~55℃/10~90%
Dimension(W×D×H): 2U, 440mm×450mm×95mm
Weight: 9.8Kg（without HDD）
